QC2508 2.5MM pitch Automotive waterproof connector

Similar products：JAE

∧ ∨

Part Series: QA2508

Pitch: 2.5mm

Poles: 02p

Temperature Range: -40℃~ +105℃

Rated voltage: 250V AC DC

Rated current: 5.0A AC DC



View video Send message Inquiry

Product details

-

Technical Parameters

Key attributes


  • Waterproof connectors designed specifically for automotive applications;

  • The main body is equipped with a hinged back cover, which forms a pre installed waterproof structure by pressing and sealing the back cover;

  • After riveting the terminal, it is directly inserted into the back cover hole to protect the sealing plug and reduce the production process of the wiring harness.

Industry-specific attributes

Type
HOUSING
Application
Automotive
Gender
WIRE HARNESS

Other attributes

Place of Origin
Zhejiang, China
Brand Name
JKUN
Model Number
QC2508
Product name
QC2508Y/T
Material
UL94 V-0
Pin
02
Pitch
2.5mm
Compliance
USCAR2.0,QC/T1067-2017
Rated Current
5A
Rated Voltage
250V AC/50V DC
Insulation Resistance
100M Ohm
Withstand Voltage
1000V AC/min
Temperature Range
-40℃~ +105℃
Wire Diameter
0.3~0.5m㎡
